Plate and Tube Integrated Cnc Plasma Cutting Machine
Product Features
--Cutting steel type: round tube
--Figures can be cut: variety of graphics by outspreading intersecting line, can be with bevel.
--Control Axies: 3 axies.
--Diameter: 60 - 600mm or customized (bigger diameter)
--Bevel cutting range: oxyfuel 45 degree, plasma 45 degree.
--Cutting methods: plasma and oxyfuel cutting.
--Pipe max length: 12m
--Pipe clamping method: chunk
--Power - driven: high precision AC servo and dedicated planetary reducer
--Control system: a dedicated intersection line, 6 - axis controller, with quantitative intersection line cutting macro library.
--Cutting steel type: round tube
--Figures can be cut: variety of graphics by outspreading intersecting line, can be with bevel.
--Control Axies: 3 axies.
--Diameter: 60 - 600mm or customized (bigger diameter)
--Bevel cutting range: oxyfuel 45 degree, plasma 45 degree.
--Cutting methods: plasma and oxyfuel cutting.
--Pipe max length: 12m
--Pipe clamping method: chunk
--Power - driven: high precision AC servo and dedicated planetary reducer
--Control system: a dedicated intersection line, 6 - axis controller, with quantitative intersection line cutting macro library.
